Resolution: 1280 x 800 WXGA
Luminance: 500 cd/m²
Contrast Ratio: 800:1
Viewing Angle: H 89°/89°, V 89°/89°
LED Lifetime: 50k h
Anti-Glare: Yes
CPU: NXP® i.MX 8M Plus QuadCore 1.8 GHz
RTC: RV-8803-C7 (±3 ppm)
RAM: 2 GB DDR4
Primary Mass Storage: eMMC, 16 GB
USB 3.2 Gen 1 Host: 2 (Type A, bottom)
Ethernet 10/100/1000-BaseT: 2 (1x RJ45; 1x RJ45 PoE ready)
Ambient Temperature: 0 to +50°C
Cooling: Passive (fanless)
IP Class: IP65 Front / IP20 Rear
Power: 24 VDC ± 20% / min. PoE+ (Class 4)
Power Button: No
Reset Button: Yes (bottom)
Config Button: Yes (bottom)
Power/Error/User LED: Yes (RGB-LED, bottom)

Software:

PA10009871  Linux Yocto 5.0 (scarthgap) Webconfig
