Resolution: 1280 x 800 WXGA
Luminance: 400 cd/m²
Contrast Ratio: 1000 : 1
Viewing Angle: H 88°/88°, V 88°/88°
LED Lifetime: 50k h
Anti-Glare: Yes
CPU: NXP® i.MX 8M Plus QuadCore
TPM 2.0: Infineon SLB9670
RTC: RV-8803-C7 (±3 ppm)
RAM: 1 GB DDR4
Primary Mass Storage: eMMC, 8 GB
USB 3.0 Host: 2 (Type A, bottom)
microSDCard Slot: 1
Ethernet 10/100/1000-BaseT: 2 (RJ45)
EIA-232: 1 (Sub-D)
Ambient Temperature: 0 to 50°C
Cooling: Passive (fanless)
IP Class: IP65 Front / IP20 Rear
Power: 12 - 24 VDC ± 20%
Power Button: No
